Digital Truck Scale of Manufacturer

Digital Truck Scale of Manufacturer
1 Enclosed construction with U-beam
2 Anti-bending design
3 Easy to install and maintain

Payment & Shipping Terms:

Price:	FOB USD 3000~13000 / Set Get Latest Price
Minimum Order Quantity:	1 Set/Sets attainable
Port:	Shenzhen or Guangzhou
Packaging Details:	20' or 40' container: modules of digital truck scale platform is fastened together by bolts; load cell , indicator and other accessories are packed in cartons.
Delivery Time:	within 15 days
Payment Terms:	L/C,T/T,Western Union,MoneyGram
Supply Ability:	100 Set/Sets per Month attainable

Digital Truck Scale of Manufacturer

Features

1. KG/LB switch
2. Linearity emendation
3. Overloading automatic record
4. Calibration rate inspection, print, handwork input
5. Scale body automatic calibration
6. Automatic locked function, convenient measuring parties examine
7. Trace single load cell and read out date automatically, estimating the load balance when installation
8. Display date, time, leap year, leap month, consecutive clock
9. Set zero tracing and zero span ring

Using environment

1. Safety overload: 150%
2. Humidity: <95%
3. Working temperature: -10~+40 Centigrade (indicator)

                                              -30~+65 Centigrade (load cell)

Dimensions of truck scale/weighbridge
SCS-150 dimension		SCS-80 dimension		SCS-40 dimension
Max Capability (T)	150	Max Capability (T)	80	Max Capability (T)	40
Graduation (Kg)	20	Graduation (Kg)	20	Graduation (Kg)	10
Platform size (m)	3.0×15 (16, 18, 20)	Platform size (m)	3.0×14 (15, 16, 18, 20)	Platform size (m)	3.0×7(10, 12, 14)
	3.2×16 (18, 20)		3.2×14 (16, 18, 20)		3.2×12 (14)
	3.4×16 (18, 21)		3.4×14 (16, 18, 21)	Number of modules	1 for 7m; 2 for over 7m
Number of modules	3	Number of modules	2 for 14m; 3 for over 14m
SCS-120 dimension		SCS-60 dimension		SCS-30 dimension
Max Capability (T)	120	Max Capability (T)	60	Max Capability (T)	30
Graduation (Kg)	20	Graduation (Kg)	10	Graduation (Kg)	5
Platform size (m)	3.0×16 (18, 20)	Platform size (m)	3.0×12 (14, 15, 16, 18, 20)	Platform size (m)	3×7 (9, 10, 12)
	3.2×16 (18, 20)		3.2×14 (16, 18, 20 )	Number of modules	1 for 7m; 2 for over 7m
	3.4×16 (18, 21)		3.4×14 (16, 18, 21)
Number of modules	3	Number of modules	2 for 12m,14m; 3 for over 14m
SCS-100 dimension		SCS-50 dimension		SCS-20 dimension
Max Capability (T)	100	Max Capability (T)	50	Max Capability (T)	20
Graduation (Kg)	20	Graduation (Kg)	10	Graduation (Kg)	5
Platform size (m)	3.0×15 (16, 18, 20)	Platform size (m)	3.0×12 (14, 16, 18)	Platform size (m)	2×4
	3.2×16 (18, 20)		3.2×12 (14, 16)		3×7
	3.4×16 (18, 21)		3.4×14 (16)	Number of modules	1
Number of modules	3	Number of modules	2 for 12m,14m; 3 for over 14m

Remarks

Since the limitation of standard container to scale body, scale platform are designed as small modules (or separate sections). The dimensions of such modules are: 1.5*5m (or 6m, 7m), 1.6*5m (or6m, 7m) and 1.7*5m (or 6m, 7m). The separate design not only makes it more convenient to install, uninstall and maintain, but also make the connected platform more rigid since more U-shaped beams are added to such connected platform  than the number of a whole platform. chinese, china, china-made, made-in-China, made in china. And that is why domestic customers who take scale quality into account first prefer to the export type of scale as well as foreign customers.
